Diamond cutting discs for wet tiled floors Ceram-W
Diamond cutting disc Ceram-W wet tiled floors
CUTDISC-DIA-JAGUAR-230MM
Art.-no. 0666230010
EAN 4099618394560
Register now and access more than 6,000 products
- No segments
- High quality and concentration of diamonds
- Water cooling
- No deformation, even with intensive use
- Sharp and clean cut
- Good performance and increased service life
In accordance with oSa (Organization for the Safety of Abrasives) Standard EN 13236
Datasheets(X)
Recommended for all types of ceramics, tiles, earthenware, marble and granite
Versatility (points system) | 4 of 4 points |
Service life (points system) | 4 of 4 points |
Cutting speed (point system) | 4 of 4 points |
Cut quality (point system) | 4 of 4 points |
Diameter (Ø) | 230 mm |
Cutting width | 3 |
Bore hole | 22.23 mm |
Reducing-ring internal diameter | 22.23 mm |
Segment height | 230 nm |
Segment height 2 | 230 mm |
Segment thickness | 3 mm |
Number of segments | 0 PCS |
Number of segments 2 | 0 PCS |
Total number of segments | 0 + 0 PCS |
Max. rotation speed | 8000 rpm |
Max. circumferential speed | 80 m/s |
